VSA Aseptic Sampling Valve
VSA series Aseptic sampling vavles are measured to designed for sampling medium viscosity products with about 0-1,000cP in viscosity and with particles up to 3mm in diameter. Such as Unprocessed Milk, Medical solutions, Filtered and unfiltered beer, Perfume, Creams and lotions, and much more.
Application
VSA series Aseptic sampling vavles are measured to designed for sampling medium viscosity products with about 0-1,000cP in viscosity and with particles up to 3mm in diameter. Such as Unprocessed Milk, Medical solutions, Filtered and unfiltered beer, Perfume, Creams and lotions, and much more.
Material
- Body: AISI-304 or AISI-316L
- Head: AISI-304 or AISI-316L
- Seal: EPDM or PTFE
- Valve seat and gasket comply with FDA 21CFR177.2600
Standard Design
- Available Size: 1/2" or 1"
- End connection: triclamp or weld
Technical Specification
- Max. pressure: 10bar (145psi)
- Temperature range: EPDM 32 ~ 266°F (0 ~ 130°C)
- Temperature range: PTFE 32 ~ 302°F (0 ~ 150°C)
- Surface treatment: Ra 16 ~ 32μin (0.4 ~ 0.8μm)
