PX1 Hydrocarbon Cannabis Extractor

Contact Now
PX1 Hydrocarbon Cannabis Extractor

Per Hour Processing
3-5 lb

Cycle time
30-45 minutes*

Capacity
Up to 40 lb, per 8-hr shift

Extracts
Isolate/Sauce, Distillate, Vape Pens, Shatter, Wax/Sugar, Tincture and Edibles

Size: 51” L x 46”W x 93” H
Warranty: 1-Year

Features

* Economical hydrocarbon solution for cannabis extraction

* Small footprint, big results

* Precise control over primary extraction

* Approximately 11L, 5 lb average material capacity per batch

* Rack mounted, easy load/unload material columns

* LPG rated valve systems (3/8″)

* 1/2” PTFE/SS feed hosing (UL-21 compliant)

* Viton/PTFE gaskets

* Stackable and variable filtering

* Inline dewaxing

* Vacuum jacket insulated solvent/dewax vessels

* Nitrogen/argon assist ready

* Patent pending vessel temperature control systems

* Ultra efficient internal temperature coil mechanisms

* Pre-plumbed for chillers and heaters

* CD-BC12 recirculating heat bath (see cut sheet)
* FP50-HE recirculating chiller (see cut
